Projecta 12-24V 25A INTELLI-START DC TO DC BATTERY CHARGER

Projecta 12-24V 25A INTELLI-START DC TO DC BATTERY CHARGER

Under Bonnet DC-DC Battery Charger

Regular price $690.00 NZD
Regular price Sale price $690.00
Sale Sold out
  • 25A with solar and alternator inputs
  • IP68 and IP69K, rated to 90°C
  • MPPT solar and lithium wake-up mode

Customers also bought

View full details

Description

Projecta's next generation in dual battery management provides an advanced charge simultaneously from both solar and alternator inputs. Temperature compensation allows IDC25X to provide 25A charge both in hot and cold climates making it ideal for under bonnet installation. It offers the highest level of protection against dust, water, and pressure washing (IP68 & IP69K). Its ultra-efficient power conversion maximizes battery charging while reducing strain on the charger, ensuring longevity. Engineered to meet heavy vehicle standards, it is resistant to vibration and shock. It supports simultaneous charging with solar and alternator inputs. The charger employs efficient MPPT solar charging for optimal performance, even in shaded areas. It also includes a convenient lithium wake-up mode for one-button charging activation, even if the battery's BMS is off. Backed by a 5-year warranty. Operates up to 90°C, ideal for under-the-bonnet use. Highest level of protection against dust, water, and pressure washing (IP68 & IP69K). Fully potted with thermal epoxy resin, it ensures durability and resistance. Backed by a 5-year warranty, it provides peace of mind. Utilises 3 and 5 stage charging for fast and effective charging. Automatic temperature compensation, optimises performance in different climates.

People are asking

Why do I need a DC-DC charger in my campervan?

Most modern vans have smart alternators with variable voltage output, so a direct connection will never fully charge your house battery. A DC-DC charger boosts and regulates alternator power to deliver a proper multi-stage charge to your AGM or lithium battery while you drive.

What size DC-DC charger should I choose?

A good rule of thumb is a charge current of 15-25% of your house battery capacity. A 25-30A charger suits a 100-200Ah battery, while 40-60A units suit larger lithium banks. Check your alternator can comfortably supply the extra current, and size your cable to match.

Is this charger compatible with lithium batteries?

Yes. Projecta DC-DC chargers include selectable charging profiles for lithium (LiFePO4) as well as AGM, gel and lead-acid batteries. Just make sure the correct chemistry profile is selected before first use so your battery receives the right charge voltages.
