Built-In Exterior Shower Box - Hot & Cold
Built-In Exterior Shower Box - Hot & Cold
Built-In Hot & Cold Exterior Shower Box
- Mixer lever dials in water temperature
- Quick-connect 1.5m hose and shower head
- Flush mounts on the outside of the van
Description
Description
Hot and cold water right on the outside of your van — perfect for campsite showers, post-surf rinses, and washing up before bed.
Benefits:
• Mixer lever dials in water temperature on the spot — no cold-only compromise.
• Quick-connect 1.5m shower hose and head included — pull out and go.
• Pluggable control lever rotates to adjust both flow and temperature in one move.
• Engineering plastic housing holds up to salty coastal and off-road conditions.
• 3C/CE certified components — built to an established quality standard.
• Hose and head are the same pattern as the KDAS-L01, so parts are interchangeable across both shower models.
Features:
The KDAS-L02 is the hot-and-cold version of the KDAS-L01, adding a temperature mixer lever that blends your hot and cold supply before it reaches the shower head. Note: the mounting cutout is a rectangle (90×105mm) — not the round 96mm aperture used by the cold-only and gravity inlet models — so plan your cut accordingly. Fix with four ST4.2×25 countersunk screws at 92mm horizontal, 92mm vertical, 130mm diagonal. The 115×136mm face panel fills the opening cleanly at just 15mm depth.
Seal the mounting flange with butyl tape or sikaflex. This unit requires both a pressurised hot and cold water supply — run your hot line from after your water heater, not through an inline heater. All hot water plumbing should be carried out by a qualified plumber.
Need a hot water source? See the Truma 14L Gas & 240V Water Heater.
Specifications
Specifications

People are asking
What is the difference between the KDAS-L01 and the KDAS-L02?
Do I need a specific hot water system to run the KDAS-L02?
Is the panel cutout the same size as the cold-only KDAS-L01?
