Seaflo 12V 23A Series Diaphragm Water Pump 40PSI

Seaflo 12V 23A Series Diaphragm Water Pump 40PSI

Seaflo | SKU: PL046

Regular price $79.99
Regular price Sale price $79.99
Sale Sold out
GST included.

Meet the SEAFLO 23A On‑Demand Diaphragm Water Pump—a compact, reliable choice that delivers smooth, pressurised water for your campervan or off‑grid build. With a smart pressure switch and quiet motor, it feels like home taps wherever you park.

Benefits:

  • Hands‑free water delivery—starts and stops automatically with tap use

  • Self‑primes up to 1.5 m—easy to install in remote setups

  • Runs dry without damage—built‑in protections for rugged use

  • Quiet, waterproof motor—IP54 rated for peace in your van

  • Compact & lightweight—ideal for tight spaces

Features:
The SEAFLO 23A brings trusted diaphragm pump tech in a neat, rugged design. Its integrated pressure switch senses when you open a tap and pumps up to 5.6 L/min at 4.8 bar, automatically stopping when pressure’s reached. It’s built tough with EPDM valves and a Santoprene diaphragm, runs dry safely, and primes itself from up to 5 ft deep. IP54-rated and ignition-proof, it’s ready for campervan life. You get 12 V or 24 V options, quick-attach fittings, and a waterproof casing—great for wet or dusty conditions.

Specifications

  • Voltage 12 V or 24 V
  • Flow Rate 0.5–1.5 GPM (1.9–5.6 L/min)
  • Shut-off Pressure 40–70 PSI (2.8–4.8 bar)
  • Suction Lift Up to 5 ft (1.5 m)
  • Max Water Temp 140 °F (60 °C)
  • Valves EPDM
  • Diaphragm Material Santoprene
  • Ports 5/8″ quick attach
  • Motor Protection Dry-run,
  • Waterproof IP54
  • Weight~0.6 kg
